96T series
YDS
High And Low Current Coupled Inductor
Self-leaded, surface mount.
Frequency range up to 1MHz.
Recognized by UL 60950-1.
Inductance----------------1MHz/1V.
Leakage Inductance------1MHz/1V.
| Part Number | lDC (Amps) | LW/DC (μH) | ET (V-μ sec) | Size Code | LW/0DC (μH±20%) | Max DCR (mΩ) |
|---|---|---|---|---|---|---|
| 96T-021I6NL | 22.4 | 2.10 | 3.25 | I6 | 4.00 | 3.4 |
| 96T-430C3NL | 1.1 | 43.6 | 7.83 | C3 | 77.0 | 309 |
| 96T-220C4NL | 2.7 | 21.9 | 6.90 | C4 | 39.5 | 90.5 |
| 96T-040C5NL | 6.4 | 4.025 | 3.135 | C5 | 6.575 | 23 |
